Technical Specifications

Upstream Ports (1)

Downstream Ports (4)

Power Mode Self-powered/bus-powered

Per-Port Voltage DC +5V

Per Port Current Self-Powered Mode: 500mA (max)

Bus-Powered Mode: 100mA (max) (Ports one and two only)

Operating Temperature 5º C ~ 40º C

Storage Temperature -20º C ~ 60º C

Enclosure ABS

Power Supply

Output: DC 5V, 2.1A

Plug Size: 3.5mm (outer)

1.0mm (center)

Plug Polarity: Center Positive

Main Power LED Color Definitions:

Off Not operational

Red Operational

Port Status LED Color Definitions:

Off Not operational, or no device connected

Green Fully operational

Amber Over-current condition

Important Note: Please do not connect any USB devices to the Hub until

instructed to do so in step 4 of this installation procedure.
